SKU: 962035

One-Way Livestock Gate Latch

$3928 Each


  • This latch is made for livestock bar gates made from tubing that is 1-5/8" or 2" in diameter. Shims are provided to attach to 1-5/8" tubing.
  • May be used for either in-swinging or out-swinging gates (one way only, not double acting).
  • This latch is not handed and will work with both LH and RH gates.
  • Latches automatically and can be unlatched with one hand.
  • The latching mechanism attaches to the fence post with two lag bolts (not included). The strike attaches to the gate tubing with two carriage bolts (included).
  • The design of this livestock gate hardware latch helps prevent sagging at the latch end of the gate.
  • The latch may be locked with a padlock (not included).
  • Dimensions
    • The size of the latch mechanism is approximately 6-1/2" x 2" with a 3" projection.
    • The strike is 4" tall by 4-1/2".

Store Policies & Information

Shipping & Delivery
Contact Us

We have been selling hardware and hinges for over 130 years. When you shop with us, you can count on prompt, personal customer service and reliable support.

Page Code: 962035

  • Finish Name
  • Material
  • Gate Latch Type
    Gravity Latch
  • Key Lockable
    With Padlock
  • Mounting Hardware Included
  • Mounting Hardware Type
    Carriage bolts
