Surface Mounted Rim Lock with Long Throw
    Surface Mounted Rim Lock with Long Throw
    Purchase Surface Mounted Rim Lock with Long Throw
    SKU #: C10597 Not Rated Yet

    Surface Mounted Rim Lock with Long Throw

    $100.22 Each
      HardwareSource - Checkmark In Stock  & Ships by the next day!


      • Surface mounted locking slide bolt for gates.
      • Lock and strike plate mounts to the surface of the gate and gate post.
      • Installation requires a 1-1/32" diameter hole drilled through the gate for the brass lock cylinder.
      • Throw of the square lock bolt is 2-5/8".
      • Lock is reversible, works on left-hand opening and right-hand opening gates.
      • Includes lock, strike plate, 5 keys, mounting screws and a round brass trim plate which fits over the brass lock cylinder showing on the outside of the gate.
      • Keys and lock cylinder are solid brass. Bolt is zinc chromate plated steel. Lock housing is coated with a black rust resistant finish.
      • Please note that this product is now only available with a black lock housing.
      • Important: Please note that the keyway for this lock is not the typical Schlage or Kwikset keyway. Your local locksmith will most likely not have key blanks for this lock that can be duplicated. 5 keys are included with each lock ordered.


      • Available in either "Single Cylinder" or "Double Cylinder
      • Single Cylinder locks and unlocks from the outside of the gate with a key.
      • Single Cylinder locks and unlocks from the inside with a button that you push and slide.
      • Double Cylinder locks and unlocks from both sides of the gate with a key.

      Door/Gate Thickness

      • 2" maximum gate thickness size
      • 2-3/4" maximum gate thickness size
      • The maximum depth is determined by the length of the brass cylinder


      • Available in two keyway types:
        • Locks are Keyed Differently
          • Each lock you order will have a unique set of keys
          • For each lock you order you will receive 5 keys
        • Locks are all Keyed Alike
          • All the locks you order will have keys that will open all of the other locks
          • For each lock you order you will receive 5 keys
      Slide Bolt Latch
      Prop 65 Warning
      You're reviewing Surface Mounted Rim Lock with Long Throw
      Rate Product
      No Reviews Yet

      4 Questions asked about Surface Mounted Rim Lock with Long Throw

      Q Linda Lobbestael • 12/18/2017, 12:08:19 PM Does this lock come with the keyed portion on the other side of the door so that the front facing aspect of the gate lock is the key hole and the surface mounted hardware is on the back of the gate? Thanks, Linda
      A 12/20/2017, 12:06:51 PM These locks are reversible. This means you can place the large bolt side on either the front or back of the gate, depending on the function you are looking for. In your case, you can place the large bolt portion on the back of the gate, so all you would see on the front is the small locking cylinder and round plate.
      Q Linda Lobbestael • 12/18/2017, 2:52:34 PM My door is 2 1/8 inches thick. What size should I go with? The 2" or 2 3/4"? Also, I see in the description there is an option to purchase this with a black locking mechanism but do not see the option at check out. How do you recommend I do that? Thanks, Linda
      A 12/18/2017, 3:44:15 PM We would recommend the 2-3/4" option. The lock housing is only available in black, so it will come black without making any special notes or selections.
      Q Rae Ohlert • 12/28/2017, 3:19:17 AM Does this allow for someone to exit thru the gate without a key but without permanently unlocking the latch? Almost like a fire exit.
      A 12/28/2017, 10:17:14 AM This can only be locked or unlocked at any given time. For the single cylinder model, the interior-side button would allow you to unlock the gate/door, but both sides would then be unlocked unless locked again with the key on the outside.
      Q Linda • 05/11/2021, 7:32:30 AM Will the lock work on gates that open outward as well as inward?
      A 05/11/2021, 9:18:05 AM The lock is reversible and can mount on either side of the gate, in can also work on in swing or outswing, but it depends on which side of the gate you put the part of the lock with the retractable silver bolt on.
