Mepla 270 Degree Institutional Hinge

$16.96

Per Bundle

Mepla 270 Degree Institutional Hinge
Customize: Use the options below to configure your product bundle
Mepla 270 Degree Institutional Hinge   + $13.97
Mepla Institutional Hinge Mounting Plate   + $2.69
European Hinge Screw, #6 x 5/8" - 1 Each   + $0.06

* Required Fields

In stock

Ships by the next day!
Your Customization
Mepla 270 Degree Institutional Hinge

In stock

$16.96

SKU
B10044
Summary

    Overview

    • Institutional hinge by Mepla, allows the door to open 270 degrees.
    • Made for overlay doors on a frameless cabinet with a 3/4" thick side panel.
    • Allows overlays from 10mm (3/8") to 16mm (5/8").
    • Features 3-dimensional adjustment.
    • Made from steel base material, nickel plated with a nylon latching mechanism.
    • Note: Unlike most European hinges, part of the hinge is visible along the edge of the door when the door is in the closed position.

    Features

    Specs

    More Information
    Manufacturer Grass
    Model # Hinge: 412.770.08.0015
    Mounting Plate: 317.293.66.001
    Finish Name Nickel
    Material Steel
    Cabinet Door Type Half Overlay, Full Overlay
    Cabinet Type Frameless
    Soft Closing No
    Self-Closing Yes
    Plate Connection Type Screw-On
    Opening Angle 270 Degrees
    Cup Diameter 35
    Screw Hole Spacing 48mm (1-7/8")
    Mounting Hardware Included No
    Mounting Hardware Type Five #6 x 5/8" flat head screws
