Overview
- Ball bearing
- Hold-open at 85 degrees
- Non-adjustable spring tension
- Non-handed
- For 1-3/8" and 1-3/4" door thickness
- Maximum door width 36"
- Order one set per door
- Use door stops at 90 degrees to prevent damage to the pivot
- Cover plates measure 9" by 2-1/8"
| Material | Steel |
| Weight Rating | 35 lbs Per Set |
| Action | Double Acting |
| Mounting Hardware Included | Yes |
| Mounting Hardware Type | Matching Wood Screws |
| California Residents | Prop 65 Warning |
You're reviewing
Light Duty Spring Pivot Set
No Reviews Yet
2 Questions asked about Light Duty Spring Pivot Set
Q
Dan • 09/09/2018, 6:46:24 PM
Can this be used on a hollow door?
A
09/10/2018, 11:36:52 AM
It certainly can, even hollow core doors still have solid wood framing all around the edges of the door, and will typically have enough meat to mortise this hinge into it.
Q
Steve Carter • 03/01/2019, 11:45:21 AM
Is there any way to adjust the springs on this door hinge to make it stay open what you wanted to stay open
A
03/01/2019, 2:29:13 PM
HI Steve! Unfortunately there isn't an adjustment or mechanism that would function as a hold open feature on this set. Only the Medium Duty has a Hold Open at 85 degrees.
https://www.hardwaresource.com/medium-duty-adjustable-spring-pivot-set.html
