Intermediate Pivot Hinge

In stock
Ships by the next day!


Intermediate Pivot Hinge


  • These intermediate pivots work only with our pivot hinges on the product page titled "Large Pivot Hinge".
  • An intermediate pivot hinge is used for taller doors to keep the middle part of the door in alighment with the pivot hinges at the top and bottom of the door.
  • Each hinge leaf measures 2-1/2" tall, 1-1/4" wide, and 5/16" thick. The total width of the hinge including the barrel is 2-1/2".



More Information
Model # SBIH2510
Material Brass
Action Single Acting
Mounting Hardware Included Yes
Mounting Hardware Type Matching wood screws
Made in USA No
