Blum  |  SKU: 652362

Blum Full Crank Thick Door Hinge

$589 Each

Fasteners Not Included

Description

This product page is for the hinge only. It does not include the mounting plate or screws needed for installation. Please see the bundled product page, here, For further details about this hinge.

Store Policies & Information

Shipping & Delivery
Returns
Contact Us

We have been selling hardware and hinges for over 130 years. When you shop with us, you can count on prompt, personal customer service and reliable support.

Page Code: 652362

  • Manufacturer
    Blum
  • Model Number
    B71T978
  • Finish Name
    Nickel
  • Material
    Steel
  • Cabinet Door Type
    Flush Inset, Thick Door
  • Self-Closing
    Yes
  • Plate Connection Type
    Clip-On
  • Opening Angle
    95 Degrees
  • Cup Diameter
    35mm
  • Screw Hole Spacing
    45mm (1-3/4")
  • Mounting Hardware Included
    No
  • Mounting Hardware Type
    Two #6 x 5/8" Flat Head Screws (Our SKU 652360)
