Roller Bearing Weld-On Hinge, Stainless Steel
Couldn't load pickup availability
Description
Description
- Stainless steel Roller Bearing Weld on hinge
- Weld-On hinge is designed to attach to a flat gate frame and either a round or flat gate post.
- Weight rated for a gate weighing up to 2000 lbs (per pair of hinges).
- The pivot arm has an oval slot for adjustability (1/2" of adjustment) of the gap between the gate frame and the post after installation.
- This hinge is sold by the each. You would normally order 2 or more hinges for each gate you are hanging.
- Construction:
- Made from 100 per cent stainless steel
- All components are stainless steel, including the bearings, pivot bolt, washers, nut, etc.
- Features two sealed roller bearings, no greasing required
Store Policies & Information
Store Policies & Information
Shipping & Delivery
Returns
Contact Us
We have been selling hardware and hinges for over 130 years. When you shop with us, you can count on prompt, personal customer service and reliable support.
Page Code: 980012
-
Manufacturer
-
Finish Name
-
MaterialStainless Steel (304)
-
Weight Rating
-
Width
-
Height
-
BearingsRoller Bearing
